Zoeller sump and sewage basins collect and contain wastewater before it is removed from a building’s system by way of a submersible sewage pump. It is a critical part of any wastewater (sewage, effluent, sump) system. Commonly constructed with fiberglass or high grade plastic, basins are heavy duty containers. They come in a variety of system types (simplex or duplex), sizes, and applications. Some basins operate with multiple types of pumps while others are designed expressly to be paired with a specific pump. Basins sit below grade while the pump itself sits at the bottom of the basin. How it functions is simple: wastewater enters the basin through an inlet pipe or port. The wastewater accumulates in the basin until it reaches a certain level, at which point your sewage pump will activate (by way of a float switch or preset control) and pump the wastewater through a discharge pipe out of the building to a municipal sewer or septic tank. Features Available in high-density polyethylene structural foam, polyethylene or fiberglass Ideal for residential, commercial and industrial applications Complete with necessary sealing hardware and flanges Available with 2” or 3” vent and 2” or 3” discharge Centerline of hub is located 10-1/2” (26.7 cm) from top of basin (standard), custom locations available Polyethylene sewage pump basins are IAPMO approved For 10’ (3 m) stack test models, refer to charts Sealed, radon basins for sump pumps in 18” x 22” (46 x 56 cm) and 18” x 30” (46 x 76 cm) sizes Polyethylene sump basins available with plastic, non-sealed covers in 18" x 22" (46 x 56 cm) Sewage basins are watertight and gas-tight when properly installed Durable steel cover with gasket standard on simplex and duplex sewage basins One-piece, seam-free construction on all basins Duplex covers include two pump plates and an inspection plate Ready to install for economical and simple installation Dimensional engineering data available Temperature rated 130 °F (54 °C) Fiberglass models available that will pass the 10’ (3 m) water stack test—refer to charts (L.A. – RR-5311) Various custom diameters and lengths available in fiberglass, consult factory (also with 10’ (3 m) water stack test) Consult factory for larger size basins or special applications Notes Basins are not designed to be installed where saturated soil hydrostatic pressure extends above the top of the pit unless the pressure is relieved by an independent drainage system. Basin cover vent and discharge seals may be rubber insert or bolted on flange design. ZOELLER BASINS Model Comparison Chart Model Dimensions Simplex/Duplex Discharge Size Vent Size Capacity (Gallons) 31-0444 18"x22" 22 31-0251 18"x22" 22 31-0249 18"x21" 1-1/2" 3" 18 31-1162 18"x30" Simplex 30 31-0080 18"x30" Simplex 30 31-2325 18"x30" n/a n/a 30 31-2229 18"x30" Simplex 30 31-0606 18"x30" Simplex 2" 30 31-0158 18"x30" Simplex 30 31-2380 18"x30" 30 31-2379 18"x30" 30 31-1338 18"x30" Simplex 2" 2" & 3" 30 31-1748 18"x30" Simplex 30 31-1855 18"x30" Simplex 30 31-0091 18"x30" Simplex 2" 2" 30 31-0615 18"x30" Simplex 2" 2" 30 31-1935 24"x24" Simplex 31-0084 18"x30" Simplex 2" 3" 30 31-0082 18"x30" Simplex 3" 3" 30 31-0608 18"x30" Simplex 2" 2" 30 31-0081 18"x30" Simplex 2" 2" 30 31-1098 18"x30" Simplex 2" 2" 30 31-1099 18"x30" Simplex 2" 2" 30 31-1100 18"x30" Simplex 3" 3" 30 31-1101 18"x30" Simplex 2" 3" 30 31-0159 18"x30" Simplex 2" 2" 30 31-0162 18"x30" Simplex 2" 3" 30 31-0161 18"x30" Simplex 3" 3" 30 31-0154 18"x30" Simplex 2" 2" 30 31-0155 18"x30" Simplex 3" 3" 30 31-0157 18"x30" Simplex 2" 3" 30 31-1144 24"x30" Simplex 60 31-0214 18"x30" Simplex 2" 2" 30 31-1096 24"x36" Simplex 31-0217 18"x30" Simplex 2" 3" 30 31-0215 18"x30" Simplex 3" 3" 30 31-1997 24"x24" Simplex 2" 2" 31-1145 30"x36" Duplex 108 31-1832 24"x30" Simplex 60 31-0039 24"x30" Simplex 2" 2" 60 31-0042 24"x30" Simplex 2" 3" 60 31-0040 24"x30" Simplex 3" 3" 60 31-1102 24"x36" Simplex 2" 2" 31-1103 24"x36" Simplex 3" 3" 31-1104 24"x36" Simplex 2" 3" 31-0004 24"x30" Simplex 2" 2" 60 31-0006 24"x30" Simplex 3" 3" 60 31-0027 24"x30" Simplex 2" 3" 60 31-0071 30"x36" Duplex 2" 2" 108 31-0221 24"x30" Simplex 2" 3" 60 31-0866 24"x48" Simplex 31-0218 24"x30" Simplex 2" 2" 60 31-0219 24"x30" Simplex 3" 3" 60 31-0044 30"x36" Duplex 3" 3" 108 31-0043 30"x36" Duplex 2" 2" 108 31-0046 30"x36" Duplex 2" 3" 108 31-0594 24"x72" Simplex 31-1106 30"x36" Duplex 3" 3" 108 31-1107 30"x36" Duplex 2" 3" 108 31-1105 30"x36" Duplex 2" 2" 108 31-0047 36"x36" Duplex 2" 2" 159 31-0048 36"x36" Duplex 3" 3" 159 31-0050 36"x36" Duplex 2" 3" 159 31-0222 30"x36" Duplex 2" 2" 108 31-1830 30"x48" Simplex 31-0072 30"x36" Duplex 3" 3" 108 31-0074 30"X36" Duplex 2" 3" 108 31-0946 24"x60" Simplex 31-1451 36"x60" Duplex 31-0010 36"x36" Duplex 2" 2" 159 31-0011 36"x36" Duplex 3" 3" 159 31-0057 36"x36" Duplex 2" 3" 159 31-1831 30"x60" Simplex 31-0223 30"x36" Duplex 3" 3" 159 31-0225 30"x36" Duplex 2" 3" 159 31-1586 30"x72" Simplex 31-1450 36"x48" Duplex 31-1452 36"x72" Duplex 31-0125 48"x48" Duplex 3" 3" 376 31-0124 48"x48" Duplex 2" 2" 376 31-0127 48"x48" Duplex 2" 3" 376 DIMENSIONS DIAGRAM SIMPLEX & DUPLEX BASINS THICKNESS OF BASINS THICKNESS OF COVERS BROCHURE Zoeller Sump-Sewage Basin Brochure INSTALLATION INSTRUCTIONS Zoeller Basin Installation Instructions Pump Products application engineers are standing by to help you find the right pump, as well as to provide price quotes, stocking availability and shipping information. Call our toll free number 1-800-429-0800 to speak to an expert today.

This series is ideal for homes, farms, trailer courts, motels, restaurants and institutions where drain facilities are below existing sewer lines. Indoor sewage applications only, 910-0030 or 910-0031 includes: Two automatic pumps One 10-0804 Smart Pak Residential Alternator with alarm One [P/N 31-1105] 30” x 36” (76 x 91 cm) polyfoam basin with 2” vent/discharge Two 30-0101 Tri-Check® Valves Basins Polyethylene structural foam, polyethylene or fiberglass Check valves 2” cast iron and 2” PVC full flow design Notes  Zoeller recommends a High Water Alarm for added protection. See FM0732 for available models. Maximum temperature rated at 130 °F (54 °C). The packages listed are available in 2” and 3” vertical discharge and vent. Consult factory for other combinations and prices. Polyethylene basins recommended for indoor installations only. ZOELLER 910 SERIES SEWAGE SYSTEMS Model Comparison Chart Model Discharge (NPT) HP Voltage Pump Model Basin Dimensions Vent Size 910-0023 2" 4/10 115 BN264 18"x30" 2" 910-0024 2" 1/2 115 BN267 18"x30" 2" 910-0016 2" 1/2 115 M267 18"x30" 2" 910-0018 2" 1/2 115 M267 18"x30" 2" 910-0026 2" 1/2 115 BN267 18"x30" 2" 910-0007 2" 1/2 115 M267 18"x30" 3" 910-0005 2" 1/2 115 M267 18"x30" 2" 910-0009 2" 1/2 115 M267 18"x30" 2" 910-0006 2" 1/2 230 D267 18"x30" 2" 910-0008 2" 1/2 230 D267 18"x30" 3" 910-0030 2" 4/10 115 M264 30"x36" 2" 910-0031 2" 1/2 115 M267 30"x36" 2" PERFORMANCE CURVES DIAGRAM TDH FLOW PER MINUTE BROCHURE Zoeller 910 Series Sewage Systems Brochure Pump Products application engineers are standing by to help you find the right pump, as well as to provide price quotes, stocking availability and shipping information. Call our toll free number 1-800-429-0800 to speak to an expert today.

Sewage system packages include a sewage pump and various other accessories to help maintain your system. Most packages in this listing will include a basin to house the pump and other accessories. Simplex (one pump) packages are ideal for domestic or small business systems. Duplex (two pump) packages are better for multi-unit residences (such as apartment buildings) and for commercial or industrial use. We also carry sewage system packages from manufacturers such as Goulds, Barnes and Zoeller. Pump Products' applications engineers are happy to work with customers to figure out the right pump for your application and budget. Call 1800-429-0800 to speak to an expert. Subscribe to our channel for more how-to guides, product highlights and general information about pumps.

The 1GA/2GA series of Grinder Pumps from Goulds are designed for municipal, commercial, and industrial pressure sewage systems or applications that require high head. This series has a cutter system designed to reduce sewage to a fine slurry. The cast iron, semi-open, non-overloading multi-vane impeller features pump out vanes for mechanical seal protection. Cast iron, volute type casing provides high efficiency operation and can adapt for a slide rail system. A two coat paint system also adds superior surface protection. A float leakage sensor comes standard on all models. A small internal float switch is used to detect the presence of water in the stator chamber. The float leakage sensor, when activated, will cause the patented 24 volt MiniCAS (control and status) monitoring relay to signal an alarm and, if desired, stop the pump. The MiniCAS 24 volt relay can be ordered separately for installation in a control panel by a UL or CSA certified panel shop or as a built in option in the control panel. The 1GA/2GA Series from Goulds Water Technology features an air filled, NEMA type B squirrel cage induction motor. The motor is designed for 15 evenly spaced starts per hour and features built in thermal sensors that provide an over temperature signal to the Mini CAS monitoring relay mounted in the control panel. A common pump motor shaft and compact seal design permits short overhang, minimizing shaft deflection. Motor casings have integral cooling ribs for maximum heat dissipation and the shaft mounting is a robust maintenance-free design featuring pre-greased ball bearings. The junction chamber is completely sealed off from the surrounding liquid and incorporates a separate gland assembly with a strain relief clamp. This series is also available in optional Explosion Proof construction. GOULDS 1GA/2GA GRINDER PUMPS Model Comparison Chart Model Discharge HP Voltage Phase GPM Max. Head 1GA71H2CD 1-1/2" NPT 4 200 3 56 120' 1GA71H4CD 1-1/2" NPT 4 460 3 56 120' 1GA71H3CD 1-1/2" NPT 4 230 3 56 120' 1GA71G1LD 1-1/2" NPT 3 230 1 42 105' 1GA71G1HD 1-1/2" NPT 3 230 1 55 95' 2GA81J4ED 2" NPT 6 460 3 162 76' 1GA81J2BD 1-1/2" NPT 6 200 3 86 135' 1GA81J4BD 1-1/2" NPT 6 460 3 86 135' 2GA81J3ED 2" NPT 6 230 3 162 76' 1GA81J3BD 1-1/2" NPT 6 230 3 86 135' 2GA81J2ED 2" NPT 6 200 3 162 76' 2GA81H1KD 2" NPT 5.4 230 1 158 53' 1GA81H1GD 1-1/2" NPT 5.4 230 1 92 117' 2GA31J1FD 2" NPT 9.4 230 1 200 98' 2GA31K3DD 2" NPT 11 230 3 196 108' 2GA31K3AD 2" NPT 11 230 3 92 178' 2GA31K2DD 2" NPT 11 200 3 196 108' 2GA31K4DD 2" NPT 11 460 3 196 108' 2GA31K2AD 2" NPT 11 200 3 92 178' 2GA31K4AD 2" NPT 11 460 3 92 178' 2GA31J1JD 2" NPT 9.4 230 1 94 148' PERFORMANCE CURVES   DATA PLATE INTERPRETATION CONSTRUCTION DETAILS GENERAL DESIGN MOTOR DATA   BROCHURE Goulds 1GA/2GA Grinder Pump Brochure PUMP SPECIFICATIONS Goulds 1GA/2GA Grinder Pump Specifications INSTRUCTION MANUAL Goulds 1GA/2GA Grinder Pump Instruction Manual APPLICATION DATA Goulds 1GA/2GA Grinder Pump Application Data REPAIR PARTS Goulds 1GA/2GA Grinder Pump Repair Parts DIMENSIONS Goulds 1GA/2GA Grinder Pump Dimensions PERFORMANCE CURVES Goulds 1GA/2GA Grinder Pump Performance Curves Pump Products application engineers are standing by to help you find the right pump, as well as to provide price quotes, stocking availability and shipping information. Call our toll free number 1-800-429-0800 to speak to an expert today.

For the last 10 years, your sump pump has been steadily working and soldiering on in your basement. But the day has finally come. It’s outlasted your kid graduating high school and your pet gold fish but at last, Father Time has taken his toll. As sad as this may be (even more sad than that scene in the Lion King), there’s a silver lining to all this. It’s time for a shiny new pump to come in and take over. Here at PumpProducts.com, we hear this sad tale every day but that’s why we have experts standing by, ready to help you pick out a suitable replacement. Selecting the right replacement pump can truly be a daunting task. Numerous classifications and scores of different models all built to different specifications and applications can leave some people overwhelmed. That's why our experts are here to help. Below you will find five general things to know before you pick out a new pump including some questions our experts might even ask. What Are You Pumping The first and perhaps most obvious thing to keep in mind when selecting a new pump is of course knowing what you need to pump. Having a pump that is not suited for a certain type of fluid can lead to corrosion or unnecessary wear and tear. There are pumps designed to pump all sorts of materials including oil and chemicals while others can only pump water. Some pumps can also handle solids such as slurry and waste while others are designed to only handle liquid. Knowing if you require a pump that is designed to handle certain fluids and solids is essential. Where Are You Pumping This may also seem obvious at first but knowing where you’re pumping is also important. If you need a transfer pump to move water from your pool cover, you need a compact and mobile pump that has a garden hose adapter (like the Liberty 331). The location of your application and pump accessory requirements may be a factor in determining what pump you need. Some pumps are submersible, meaning they can operate submerged in water, while others can be irrevocably damaged if water gets into motor components. If a pump is going to be stationary, you may even need to purchase a basin. A pump’s surroundings can help determine how long its service life lasts. Also make sure the power cord on your pump is a suitable length for your application. Flow Rate Understanding flow rate can perhaps be the single most important factor when selecting the right pump for your application. Flow rate is the rate you want to transfer fluid at and basically determines the overall effectiveness of a pump. Flow rate is generally measured in gallons per minute (GPM). A larger flow rate means a larger pump size is needed. Inlet Size Pump inlet sizes can vary but are typically between 1-6 inches. Centrifugal pumps work by sucking water in through an inlet and discharging the water through an outlet valve. Larger inlet sizes allow for larger amounts of water to be pumped out faster. Head & Pressure "Head" refers to the longest distance in terms of height a pump is able to pump water before gravity takes over. If you try to pump water higher than a pump’s maximum head, the flow rate will be zero. It can be beneficial to select a pump that has a maximum head greater than the head needed for your application. Selecting a pump can be challenging. If you have any doubts of this, just check out our extensive pump catalog and scroll through the myriad of pumps we offer. If you need any help, give our experts a call and let them do the work for you! Pump Products application engineers are standing by to help you find the right pump, as well as to provide price quotes, stocking availability, and shipping information. Call our toll free number 1-800-429-0800 to speak to an expert today.

Is there anything more magical than the mighty pump A concept so simple and elegant - the transportation of fluid from one place to another - has changed human society and delighted people the world over. People are always coming up to me saying “hey Inspector, aren’t pumps great” and “You’re so lucky that you get to work with pumps everyday!”  And as I always say in return: Brother, you ain’t lying. Of course, while everyone loves pumps, not all truly grasp just how important pumps are to the functioning of everyday society. For instance, did you know that pumps are the second most used mechanical instrument (regardless of application) in the world after the motor I bet that fun fact knocked you right out of your seat friend. But it’s true and it underlines how important pumps are to so many areas. An old adage in the pumping industry is that pumps are something you never think about until one breaks and suddenly getting a new one is all you can think about. Millions of people across the country that live in rural or outlying areas rely on pumps to get their water from a well. For these people, pumps are quite literally a lifeline. If you get your water from a municipal source, you might associate pumps more with wastewater or groundwater removal from a specific area. For instance, if you are a homeowner in an area that is prone to flooding, you surely know the importance of your basement sump pump. If you are a property manager and people are constantly flushing towels, diapers and plastic wipes down the toilets on your property, there’s a good chance you’ve familiarized yourself with grinder pumps. And so on. The majority of pumps that Pump Products sells can probably be segmented into a choice few categories (sump, sewage, well), a wide variety of other pump types are available as well. Pumps for hazardous areas (chemical resistant, explosion proof), pumps for residential areas, pumps for ice machines - all exist. There are probably as many types of pumps out there as there are possible fluid moving applications. Pumps can be used for aesthetic purposes, such as with water feature/fountain displays. These water features can range from the fountain in your backyard to the Bellagio fountains in Las Vegas. Anytime you see some crazy water display, remember that a pump is doing the hard work. Did you know that pumps are also involved in fermenting wine and in breweries. That’s right, the glass of wine or bottle of beer that you are (responsibly) sipping while reading this blog is only possible because of pumps. And in fact that’s the point of this blog and the “Made Possible by Pumps” campaign: to educate the populace on the important power of pumps. Over the coming weeks, I will highlight how different aspects of human society - commerce, customs, clothing, manufacturing, entertainment, art - are powered (at least in part) by pumps. Hopefully this endeavour will let you appreciate these simple but wondrous machines.  So look out for blog posts, features and other content tagged “Made Possible by Pumps” to learn more! Pump Products application engineers are standing by to provide technical assistance, price quotes or to answer any questions you may have regarding pumps. Call our toll free number 1-800-429-0800.
